How to Install Inflatable Boat Fenders in 6 Simple Steps:

1. Lay the fender flat – Position it on its side with D-rings facing the dock.

2. Attach swivel shackles – Secure them to the D-rings for flexibility.

3. Screw in half saddles – Align with D-rings and screw 60-65mm from the edge.

4. Flip the fender over – Release the inflation valve and secure the plug.

5. Attach the shackle pin – Thread it through the half saddle, ensuring it faces away from the tube.

6. Inflate to 2 PSI – Use an electric or foot pump until firm.

Pro Tip: Attach a safety line and tie to dock.

​
